MICROSINT-SS Sinter powder metals filters offers a wide range of sintered metal powder filtration products for a variety of applications and industries including chemical processing, refining, hot gas, pharmaceuticals, steam service, and many more.

A unique sintering technology is used to create products with significant performance, durability, and reliability advantages. MICROSINT-SS, a industry exclusive, allows for removal of sub-Micronics particles without the high pressure drop.

MATERIAL OF CONSTRUCTION

Filter Medium* Stainless Steel 316L
Support layer* SS316
Core/Cage/End Caps* SS316
O ring/Gasket Silicon/EPR/PTFE/Viton

CARTRIDGE DIMENSIONS (NOMINAL)

Outer Diameter 63.0 mm (2.48”) |75 mm (2.95”)*
Length 10”, 20”, 30”, 40”
Effective filtration area (10" cartridge)* 0.10 m2

MICRON RATINGg(µ)*

Micron Rating(µ) 0.5, 1, 2, 5, 10*

OPERATING CONDITION

Temperature(Max) 150 0C/3020F
Pressure (Max) 7 Bar /101.5 psi
pH value 1-14

FEATURES & BENEFITS

  • Sinter Powder Media
  • Hot Application Usage
  • Low Pressure drop
  • Consistent Filtration
  • High Dirt Holding

APPLICATIONS

  • Suitable for the extreme operating environments
  • Pharmaceuticals: Prefiltration & decarbonate filtration
  • Recovery of catalyst
  • Food & Beverages: Filtration of viscous liquid with high temperature.
  • Fine Chemicals: Strong acid & alkaline filtration.
  • Water: Filtrate the O-zone containing water.
  • Steam filtration
